Stylish and compact design with advanced customization capabilities

• IML (Insert Molding) patented unique technology for high quality and robust on-demand 4-color graphics design.
• Large choice of colors for the plastic parts at the back.

High level of functionality and performance

• Supports all smart cards/tags technologies, including NFC, 2D barcodes, co-branded bank & transit contact-less cards.
• Provides the operator with the ability to introduce new and more flexible ticketing products in the future.
• Ticket reloading facility.
• Capability to integrate with on-board bus driver consoles and intelligent transportation systems.
• Provides fast processing to speed-up boarding time.
• Features easy and comfortable operation.

Always-on information

• Clearly advise passengers with colored pictograms, visual indicators, buzzer and audio assistance for visually-impaired travelers (status of validation, information regarding smart card validity, season ticket status, balance, list of contracts, recent transactions).
• Real-time passenger information such as:
  – network maps to help choose or reach destinations, progression in the line, ‘Next stop’ indicator, flash alerts during disruptions.
  – local information based on vehicle location systems (GPS) and GPRS communication of driver console, e.g dynamic advertisements regarding local shops, nearest cinema with schedules, transport service transfers at next stop, departure times upon arrival at each stop.

Robustness, reliability

• Qualified and well-proven subparts for similar use.
• Optimized to meet all the requirements of the mobile world of bus and tram travel.

Future-proof open architecture

• Based on the very popular open-source Android Operating System to make additional features, advanced services and applications in Axio Touch easy and fast to be developed by any 3rd party.

Cost effective

• Service-friendly design, can be easily and quickly replaced.
• Remote or local access for maintenance.
• Remote software downloading for updates.

CPU e Memória

• Processador Freescale MC9328 iMX21 (266MHz) 32-bit
• 64Mb Flash ROM (com área de boot)
• 128 Kb RAM
• 128 Kb RAM (memória dinâmica)
• O relógio/calendário interno é sincronizado durante a comunicação com o computador
• Sistema de recuperação e monitorização de software

Altifalante e amplificador

• Altifalante integrado
• Possibilidade de reproduzir som MP3 (Voz – Multi-Idioma) Opcional
• Som programável (amplificador com pico de 0,5 watt)

Interfaces

• USB tipo 2
• 10 Mbps Ethernet
• Wireless 802.11b/g disponível opcional

Leitor de cartões sem contacto

• Leitor ISO 14443 tipo A e B compatível ITSO
• Compatível Calypso
• Possibilidade de colocação até 2 SAM’s
• Opção expansão até 4 SAM’s.

Caixa

• Resistente a actos de vandalismo e roubo
• Construído em ABS e composto Policarbonato
• Faces exteriores limpas, arredondadas, sem parafusos expostos
• Desenhada para resistir á entrada acidental de água

Display Passageiro

• Ecrã a cores de 89mm (3.5“)
• Resolução QVGA (240*320) > 262K cores
• O TFT permite um brilho incomparável, e facilidade de adaptação a todos os ambientes
• Contraste e brilho controlado via software.
• 3 Led’s (Vermelho, Laranja e Verde) permite fácil visualização do resultado da operação efectuada

Teclado

• Opção de 6 teclas de longa duração para o passageiro opcionalmente seleccionar

Compatibilidade Electromagnética

• Susceptibilidade testado para EN 61000-6-2 2001
• Emissões testada a EN 61000-6-4 2001

Temperatura

• Funcionamento: -10°C a +70°C (-20ºC a +70ºC)*
• Armazenamento: -20°C a +80°C
• * Se ficar permanentemente ligado

Certificação CE
